| Bearing Unit NO. |
Shaft Dia d |
Dimensions(mm) |
Bearing No. |
Housing No. |
Housing
Wt (kg) |
| (in) |
(mm) |
a |
w |
h |
D |
s |
j |
Bi |
n |
l |
b |
UCHE201-8
UCHE202-9
UCHE202-10
UCHE203-11
UCHE204-12
UCHE201
UCHE202
UCHE203
UCHE204 |
1/2
9/16
5/8
11/16
3/4
|
12
15
17
20 |
65 |
91 |
58 |
30 |
M16 |
21 |
31 |
12.7 |
25 |
38 |
UC201-8
UC202-9
UC202-10
UC203-11
UC204-12
UC201
UC202
UC203
UC204 |
HE201
HE202
HE203
HE204 |
0.25
0.25
0.25
0.4 |
UCHE205-13
UCHE205-14
UCHE205-15
UCHE205-16
UCHE205 |
13/16
7/8
15/16
1
|
25 |
70 |
99 |
64 |
35 |
M20 |
22 |
34 |
14.3 |
28 |
38 |
UC205-13
UC205-14
UC205-15
UC205-16
UC205 |
HE205 |
0.54 |
UCHE206-17
UCHE206-18
UCHE206-19
UCHE206-20
UCHE206 |
1-1/16
1-1/8
1-3/16
1-1/4
|
30 |
85 |
114 |
72 |
40 |
M24 |
24 |
38.1 |
15.9 |
32 |
40 |
UC206-17
UC206-18
UC206-19
UC206-20
UC206 |
HE206 |
0.96 |
UCHE207-20
UCHE207-21
UCHE207-22
UCHE207-23
UCHE207 |
1-1/4
1-5/16
1-3/8
1-7/16
|
35 |
90 |
122 |
76 |
40 |
M24 |
24 |
42.9 |
17.5 |
32 |
49 |
UC207-20
UC207-21
UC207-22
UC207-23
UC207 |
HE207 |
0.81 |
UCHE208-24
UCHE208-25
UCHE208 |
1-1/2
1-9/16
|
40 |
100 |
135 |
85 |
40 |
M24 |
24 |
49.2 |
19 |
36 |
45 |
UC208-24
UC208-25
UC208 |
HE208 |
1.2 |
UCHE209-26
UCHE209-27
UCHE209-28
UCHE209 |
1-5/8
1-11/16
1-3/4
|
45 |
110 |
145 |
90 |
40 |
M24 |
24 |
49.2 |
19 |
40 |
46 |
UC209-26
UC209-27
UC209-28
UC209 |
HE209 |
1.33 |
UCHE210-29
UCHE210-30
UCHE210-31
UCHE210-32
UCHE210 |
1-13/16
1-7/8
1-15/16
2 |
50 |
110 |
145 |
90 |
40 |
M24 |
24 |
51.6 |
19 |
40 |
46 |
UC210-29
UC210-30
UC210-31
UC210-32
UC210 |
HE210 |
1.42 |
