| Bearing Unit NO. |
Shaft Dia
d |
Dimensions(mm) |
Bolt Used |
Bearing
No. |
Housing No. |
Housing
Wt (kg) |
| (in) |
(mm) |
a |
e |
i |
s |
z |
Bi |
n |
mm |
in |
UCCF201-8
UCCF202-9
UCCF202-10
UCCF203-11
UCCF204-12
UCCF201
UCCF202
UCCF203
UCCF204 |
1/2
9/16
5/8
11/16
3/4
|
12
15
17
20 |
86 |
64 |
15 |
12 |
46 |
31 |
12.7 |
M10 |
3/8 |
UC201-8
UC202-9
UC202-10
UC203-11
UC204-12
UC201
UC202
UC203
UC204 |
CF201
CF202
CF203
CF204 |
0.84 |
|
|
UCCF205-13
UCCF205-14
UCCF205-15
UCCF205-16
UCCF205 |
13/16
7/8
15/16
1
|
25 |
95 |
70 |
16 |
12 |
51 |
34.1 |
14.3 |
M10 |
3/8 |
UC205-13
UC205-14
UC205-15
UC205-16
UC205 |
CF205 |
1 |
UCCF206-17
UCCF206-18
UCCF206-19
UCCF206-20
UCCF206 |
1-1/16
1-1/8
1-3/16
1-1/4
|
30 |
108 |
83 |
18 |
12 |
55 |
38.1 |
15.9 |
M10 |
3/8 |
UC206-17
UC206-18
UC206-19
UC206-20
UC206 |
CF206 |
1.29 |
UCCF207-20
UCCF207-21
UCCF207-22
UCCF207-23
UCCF207 |
1-1/4
1-5/16
1-3/8
1-7/16
|
35 |
117 |
92 |
19 |
14 |
59 |
42.9 |
17.5 |
M12 |
7/16 |
UC207-20
UC207-21
UC207-22
UC207-23
UC207 |
CF207 |
1.61 |
UCCF208-24
UCCF208-25
UCCF208 |
1-1/2
1-9/16
|
40 |
130 |
102 |
21 |
16 |
66 |
49.2 |
19 |
M14 |
1/2 |
UC208-24
UC208-25
UC208 |
CF208 |
2.07 |
UCCF209-26
UCCF209-27
UCCF209-28
UCCF209 |
1-5/8
1-11/16
1-3/4
|
45 |
137 |
105 |
22 |
16 |
67 |
49.2 |
19 |
M14 |
1/2 |
UC209-26
UC209-27
UC209-28
UC209 |
CF209 |
2.42 |
UCCF210-29
UCCF210-30
UCCF210-31
UCCF210-32
UCCF210 |
1-13/16
1-7/8
1-15/16
2
|
50 |
143 |
111 |
22 |
16 |
71 |
51.6 |
19 |
M14 |
1/2 |
UC210-29
UC210-30
UC210-31
UC210-32
UC210 |
CF210 |
2.81 |
UCCF211-32
UCCF211-33
UCCF211-34
UCCF211-35
UCCF211 |
2
2-1/16
2-1/8
2-3/16
|
55 |
162 |
130 |
25 |
19 |
75 |
55.6 |
22.2 |
M16 |
5/8 |
UC211-32
UC211-33
UC211-34
UC211-35
UC211 |
CF211 |
3.56 |
UCCF212-36
UCCF212-37
UCCF212-38
UCCF212-39
UCCF212 |
2-1/4
2-5/16
2-3/8
2-7/16
|
60 |
175 |
143 |
29 |
19 |
86 |
65.1 |
25.4 |
M16 |
5/8 |
UC212-36
UC212-37
UC212-38
UC212-39
UC212 |
CF212 |
4.43 |
UCCF213-40
UCCF213-41
UCCF213 |
2-1/2
2-9/16
|
65 |
187 |
149 |
30 |
19 |
89 |
65.1 |
25.4 |
M16 |
5/8 |
UC213-40
UC213-41
UC213 |
CF213 |
5.37 |
UCCF214-42
UCCF214-43
UCCF214-44
UCCF214 |
2-5/8
2-11/16
2-3/4
|
70 |
193 |
152 |
31 |
19 |
98 |
74.6 |
30.2 |
M16 |
5/8 |
UC214-42
UC214-43
UC214-44
UC214 |
CF214 |
5.72 |
UCCF215-45
UCCF215-46
UCCF215-47
UCCF215-48
UCCF215 |
2-13/16
2-7/8
2-15/16
3
|
75 |
200 |
159 |
34 |
19 |
102 |
77.8 |
33.3 |
M16 |
5/8 |
UC215-45
UC215-46
UC215-47
UC215-48
UC215 |
CF215 |
6.35 |
UCCF216-50
UCCF216 |
3-1/8
|
80 |
208 |
165 |
34 |
23 |
107 |
82.6 |
33.3 |
M20 |
3/4 |
UC216-50
UC216 |
CF216 |
7.14 |
UCCF217-52
UCCF217 |
3-1/4
|
85 |
220 |
175 |
36 |
23 |
111 |
85.7 |
34.1 |
M20 |
3/4 |
UC217-52
UC217 |
CF217 |
8.38 |
UCCF218-56
UCCF218 |
3-1/2
|
90 |
235 |
187 |
40 |
23 |
122 |
96 |
39.7 |
M20 |
3/4 |
UC218-56
UC218 |
CF218 |
10.5 |
